Product Details:
|
Type: | Laboratory Furniture | Color: | Off-white And Customized |
---|---|---|---|
Size: | 1200/1500/1800*850*2350MM | Function: | Work Station |
Product Name: | PP Fume Hood Lab | General Use: | Commercial Furniture |
Material: | Polyropylene | Usage: | Lab Air Cleaning |
High Light: | Lab Equipment Portable Chemical Hoods 1800mm,Laboratory Vent Hood PP Composite 1800mm,Portable Laboratory Vent Hood 1800mm |
Specifications of fume hood lab
Product Name | Lab equipment PP composite portable chemical fume hood lab |
Size |
1200(W)*850 (D)*2350 (H) mm Customized size |
Color | white/Customized |
Cabinet Body | Anticorrosion fume hood, thickened high quality cold rolled steel plate,after acid washing, phosphide and electro galvanized,sprayed with good quality anti-corrosion static casting. The upper fume hood and the below cabinets can be divided parts |
Table | 12.7 mm solid physical &chemical plate, edge thicken to 25.4 mm, acid & alkali resistant, Shock resistant, anti-corrosion, Environment Friendly. |
Shell |
High quality steel plate spray molding with 1 mm, surface spray treatment with epoxy resin. Watering, electricity and gas installed in between the liner and shell. |
Inside lining |
5 mm thickness of strong acid and alkali resistance, organic solvents resistance, anti-corrosion materials. |
Sliding Sash | 5 mm thickness of safety explosion-proof glass,variable speed balance weight design, window height can be stopped at any position, lift freely. |
Lighting | 30W Fluorescent lamp,shielded with explosion-proof,moisture proof glass |
Guide plate | anti-corrosion, resistance to strong acid and alkali, high temperature resistant, easy to disassemble and cleaning. |
Control circuitry | Power switching, lighting and air blower,easy operation. |
Power outlet | lab standard, water proof, with dust cover |
Fan duct |
250W axial fan, working side wind speed 0.3-0.8 mm/s, exhaust volume 1080-1400m³/h, Noise less than 70 FB |
Cup Sink | Oval shaped PP Cup sink |
Water Tap | Molded in one piece copper water tap,epoxy powder coating surface with ceramic valve. |
Exhaust Duct | Anti-corrosion PP/PVC duct |
Advantage of Fume Hood:
